Technical Details

• Package / Case 8-SOIC (0.154", 3.90mm Width)
• Output Type Fixed
• Mounting Type Surface Mount
• Current - Output 50mA, 50mA
• Operating Temperature -40°C ~ 150°C (TJ)
• Output Configuration Positive
• Current - Quiescent (Iq) 50 µA
• Voltage - Input (Max) 40V
• Number of Regulators 2
• Supplier Device Package 8-SO
• Voltage - Output (Min/Fixed) 5V, 5V
• Control Features Enable
• Grade Automotive
• PSRR 60dB (100Hz)
• Voltage Dropout (Max) 0.5V @ 50mA
• Protection Features Over Current, Over Temperature
• Current - Supply (Max) 4.2 mA
• Qualification AEC-Q100
